G9SX-family modules can be connected by a logical “AND” function to implement partial/global stopping of a machine. Solid-state outputs, detailed LED diagnosis and clever feedback signals help to keep maintenance easy. The line-up is completed by expansion units with safe timing functions.

• Clear and transparent segmentation of safety functions by use of unique "AND" connection
• Solid-state outputs for long life and relay outputs in extension box available
• Detailed LED indications enable easy diagnosis
• Clever feedback signals for easy maintenance
• Category-4 according to EN954-1 and SIL 3 according to EN 61508

Flexible safety unit
